Central Slot
-
Central Slot
- 型號(hào)Central Slot
Central Slot
|
Main Parameters |
Spec. & Model |
Main Dimensions (mm) |
Manganese Plate Thickness (mm) |
|
SGB630/150C |
Length: 1500 Width: 630 |
14 |
|
|
SGB620/40T |
Length: 1500 Width: 620 |
10 |
|
|
SGB620/40Z |
Length: 1500 Width: 420 |
10 |
|
|
SGB420/30 |
Length: 1200 Width: 420 |
8（6） |
|
|
SGD420/22-30 |
Length: 1200 Width: 420 |
8（6） |
|
|
SGB26 |
Length: 1200 Width: 420 |
8（6） |
|
|
SGD320/17B |
Length: 1200 Width: 320 |
6 |
|
|
Standard |
Standard of the Ministry of Coal Industry, PRC. MT183 Scraper Conveyor Center Channel |
||
|
Use |
Mainly used in scraper conveyors and elevating conveyors of coal mines. |
||
